FSM-9, 9 Ton Mechanical Industrial Spreader

Pullertop supplies full ranges of hydraulic flange spreaders, our flange spreader tools are normally used for separating flanges, widely being used in industrial applications such as pipeline maintenance, pipeline construction, testing and flange replacement, maintenance gaskets, pressure vessels, cylinder head opening, power plants, bearing disassembly, oil and electricity drilling, motor rotor disassembly, offshore platforms, jacking work, Shipbuilding, industrial equipment, horizontal movement of workpieces and so on. Tool selection is made on the basis of the access gap between the flange faces, the flange size, and the required scope of work.

Download Catalog
Upload File

Product Description

Product Lines: Hydraulic Flange Spreader

  • Flange spreading force 9 ton
  • Spreading distance 81 mm
  • The minimum required gap is 6 mm
  • The tool is maintenance free
  • Protected against corrosion
  • It is used with a 200 N.m torque wrench
  • Ergonomic – lightweight, easy use
  • It can be operated individually or in pairs
  • Used for safely opening pipe flanges

Think Safety

Manufacturer’s rating of load and stroke are maximum safe limits. Good practice encourages using only 80% of these ratings!

Image Gallery

Series Specifications

Maximum Operating Pressure (bar) 700
Maximum Spreading Force (ton) 9
Maximum Spread (mm) 81
Tip Clearance (mm) 6
Power Source Mechanical
Weight: 9.3

Series Comparison

Model Number Max Spreading Force/Ton Tip Clearance/mm Max Spread/mm Spreader Type Oil Capacity/cm3 Weight/Kg
FSH1-14 15 6 81 Hydraulic 78 9.3
FSM-9 6 81 Mechanical * 7.5
