Product Description
Product Lines: Hydraulic Hand Pump
- Made of high-strength steel alloy material, lightweight and anti-corrosion
- Heavy-duty, formed metal handle provides rigidity, and reduces operator fatigue with grip.
- Convenient oil fill ports.
- The fill cap seal acts as a safety valve to prevent overpressurizing the reservoir.
- Max working pressure up to 2800bar
- Large oil capacity to power a wide range of hydraulic tools.
Think Safety
Manufacturer’s rating of load and stroke are maximum safe limits. Good practice encourages using only 80% of these ratings!
Image Gallery
Series Specifications
| Oil Capacity: | 1440cm3 |
| Pump Type: | Two Speed |
| Maximum Operating Pressure : | 70-280Mpa |
| Weight: | 11Kg |
Series Comparison
| Model | Usable Oil Capacity/cm3 | Pump Type | First Stage Pressure/bar | Second Stage Pressure/bar | Max handles Force/Kg | Oil Displacement Per Stroke 1st Stage (cm3) | Oil Displacement Per Stroke 2nd Stage (cm3) | Piston Stroke | Weight/Kg |
|---|---|---|---|---|---|---|---|---|---|
| 7P393 | 1440 | Two-speed | 25 | 700 | 30 | 32 | 2.5 | 25.4 | 11 |
| 20P393 | 1440 | Two-speed | 15 | 2000 | 40 | 32 | 2.5 | 25.4 | 11 |
| 28P393 | 1440 | Two-speed | 20 | 2800 | 45 | 32 | 2.5 | 25.4 | 11 |
